Specifications
Details |
|---|
Product code |
RB760iGS |
Architecture |
MMIPS |
CPU |
MT7621A |
CPU core count |
2 |
CPU nominal frequency |
880 MHz |
CPU Threads count |
4 |
Dimensions |
113 x 89 x 28 mm |
License level |
4 |
Operating System |
RouterOS |
Size of RAM |
256 MB |
Storage size |
16 MB |
Storage type |
FLASH |
Tested ambient temperature |
-40°C to 70°C |
Powering
Details |
|---|
PoE in |
802.3af/at |
PoE out |
Passive PoE up to 57V |
PoE in input Voltage |
12-57 V |
Number of DC inputs |
2 (DC jack, PoE-IN) |
DC jack input Voltage |
12-57 V |
Max out per port output (input > 30 V) |
500 mA |
Max out per port output (input < 30 V) |
500 mA |
Max total out (A) |
500 mA |
Max power consumption |
24 W |
Max power consumption without attachments |
6 W |
Ethernet
Details |
|---|
10/100/1000 Ethernet ports |
5 |
Fiber
Peripherals
Details |
|---|
Memory card type |
microSD |
Memory Cards |
1 |
Number of USB ports |
1 |
USB Power Reset |
Yes |
USB slot type |
USB type A |
Max USB current (A) |
1 |
Other
Details |
|---|
PCB temperature monitor |
Yes |
Voltage Monitor |
Yes |
Mode button |
Yes |
