Transcend 512MB INDUSTRIAL TEMP CF200I CF CARD, paměťová karta (SLC) TS512MCF200I
Transcend 512MB INDUSTRIAL TEMP CF200I CF CARD, paměťová karta (SLC) TS512MCF200I
Transcend 512MB INDUSTRIAL TEMP CF200I CF CARD, paměťová karta (SLC)
Built extra-rugged with excellent temperature flexibility and high performance, Transcend's CF200I Industrial Temp CF cards are specifically designed for industrial use and mission-critical applications.
Features:
CompactFlash Specification Version 4.1 Compliant
RoHS compliant products
Support S.M.A.R.T (Self-defined)
Support Security Command
Support Global Wear-Leveling, Static Data Refresh, Early Retirement, and Erase Count Monitor functions to extend product life
Operation Modes: PC Card Memory, PC Card IO, True IDE
True IDE Mode supports: UDMA0-5, MDMA0-4, PIO0-6 (UDMA5 as default)
True IDE Mode: Fixed Disk (Default)
PC Card Mode: Fixed Disk (Default)
Power Shield prevents data loss in the event of a sudden power outage
Specifications:
Interface(connector). Compact Flash, 50P
Form Factor: Compact Flash Card
Flash Type: SLC
Capacity(GB): 512MB
Max. R/W Performance(MB/s)(Vary by density):
- Read: 92MB/s
- Write: 70MB/s
Op. Voltage(V): 3.3V±5% or 5V±10%
Power Consumption(W): 0.76W
Op. Temp.(C): - 40C~85C
Storage Temp.(C):- 55C~100C
Humidity(%): 0%~95%
Shock(G): 1500G, 0.5ms, 3 axis
Vibration(Hz/G): 20G (Peak-to-Peak), 20Hz to 2000Hz(Frequency)
Dimensions(mm): 42.8mm × 36.4mm × 3.3mm
MTBF(hours): 4,000,000 hours
Built extra-rugged with excellent temperature flexibility and high performance, Transcend's CF200I Industrial Temp CF cards are specifically designed for industrial use and mission-critical applications.
Features:
CompactFlash Specification Version 4.1 Compliant
RoHS compliant products
Support S.M.A.R.T (Self-defined)
Support Security Command
Support Global Wear-Leveling, Static Data Refresh, Early Retirement, and Erase Count Monitor functions to extend product life
Operation Modes: PC Card Memory, PC Card IO, True IDE
True IDE Mode supports: UDMA0-5, MDMA0-4, PIO0-6 (UDMA5 as default)
True IDE Mode: Fixed Disk (Default)
PC Card Mode: Fixed Disk (Default)
Power Shield prevents data loss in the event of a sudden power outage
Specifications:
Interface(connector). Compact Flash, 50P
Form Factor: Compact Flash Card
Flash Type: SLC
Capacity(GB): 512MB
Max. R/W Performance(MB/s)(Vary by density):
- Read: 92MB/s
- Write: 70MB/s
Op. Voltage(V): 3.3V±5% or 5V±10%
Power Consumption(W): 0.76W
Op. Temp.(C): - 40C~85C
Storage Temp.(C):- 55C~100C
Humidity(%): 0%~95%
Shock(G): 1500G, 0.5ms, 3 axis
Vibration(Hz/G): 20G (Peak-to-Peak), 20Hz to 2000Hz(Frequency)
Dimensions(mm): 42.8mm × 36.4mm × 3.3mm
MTBF(hours): 4,000,000 hours
Dodatočné parametre
| Kategória: | Pamäťové karty |
|---|---|
| Záruka: | 24 mesiacov |
| Hmotnosť: | 0.06 kg |
| Kapacita pamäťovej karty: | menej ako 1 GB |
| Typ (pamäťové karty): | CF průmyslové |
