Gigabyte BRIX/GB-BRU5-225H/Mini/U5-225H/bez RAM/Intel int/bez OS/3R

Elegant design with enhanced computing power
Intel® Core™ Ultra 5 processor 225H
Intel® Arc™ Graphics, 130T GPU
Super Fast 2.5G LAN + Module Wi-Fi 7
4 x 4K Display output - 2 x HDMI 2.1 and 2 x USB Type C with DP alt mode
3 x USB 3.2 Gen2 Type A
Low Noise
VESA Support


* Barebone products do not include the operating system.
* Product may vary based on local distribution.
* Wireless module inclusion may vary based on local distribution.

Dimension
112.6 x 34.4 x 119.4 mm (W x H x D) (Slim chassis design)

Motherboard Size
105 mm x 114.49 mm

CPU
Intel® Core™ Ultra 5 processor 225H
14C, 4P+8E+2LPE, 28W

Memory
2 x SO-DIMM DDR5 slots, support up to 5600MHz
Max. 96GB
or
2 x CSO-DIMM DDR5 slots, support up to 6400MHz
Max. 96GB

LAN
2.5GbE LAN (Intel® I226V)

Wifi Card
Realtek® Wi-Fi 7 RTL8922AE

Graphics
Intel® Arc™ Graphics, 130T GPU
2 x HDMI v2.1, 4096x2160 60Hz, (TMDS, CEC)
2 x USB type C ALT (DisplayPort v2.1)

(Intel® Arc™ Graphics requires using 2 x SO-DIMM/CSO-DIMM dual channel memory)

Audio
Realtek ALC245

Expansion Slots
1 x M.2 M Key 2280 slot (PCIe Gen4x4) (PCIe Gen5x4, ready design)
1 x M.2 M Key 2280 slot (PCIe Gen4x4+SATA)
1 x M.2 E Key 2230 Wi-Fi & BT slot (Wi-Fi 7 RTL8922AE)

Front I/O
1 x Headset
2 x USB 3.2 Gen2 Type A
1 x USB 3.2 Gen2 Type C (ALT)

Rear I/O
2 x HDMI (TMDS & CEC)
1 x USB4
1 x USB 3.2 Gen2 Type C (PD IN)
1 x USB 3.2 Gen2 Type A
1 x USB 2.0 Type A
1 x RJ45

Left I/O
1 x Kensington Lock Slot

Power Supply
Input : AC 100-240V
Output : DC 20V/5A, 100W (Type-C PD)

VESA
VESA support
Supports 75 x 75 and 100 x 100 mm

Support OS
Windows 11 64bit
Ubuntu 24.10

Environment
System Environment Operating Temperature: 0°C to +35°C
System Storage Temperature: -20°C to +60°C

NPU
Intel® AI Boost NPU up to 13 TOPs
