Specifications
Details |
|---|
Product code |
CRS520-4XS-16XQ-RM |
Architecture |
ARM 64bit |
CPU |
AL52400 |
CPU core count |
4 |
CPU nominal frequency |
2 GHz |
Switch chip model |
98CX8410 |
RouterOS license |
5 |
Operating System |
RouterOS v7 |
Size of RAM |
4 GB |
Storage size |
128 MB |
Storage type |
NAND |
MTBF |
Approximately 200'000 hours at 25C |
Tested ambient temperature |
-20°C to 50°C |
Powering
Details |
|---|
Number of AC inputs |
2 |
AC input range |
100-240 |
Number of PSU slots |
2 |
Frequency (Hz) |
50-60 |
Max power consumption |
150 W |
Max power consumption without attachments |
123 W |
Cooling type |
4 fans |
Ethernet
Details |
|---|
Number of 1G/2.5G/5G/10G Ethernet ports |
2 |
Fiber
Details |
|---|
Number of 25G SFP28 ports |
4 |
Number of 100G QSFP28 ports |
16 |
Peripherals
Details |
|---|
Serial console port |
RJ45 |
Other
Details |
|---|
CPU temperature monitor |
Yes |
PCB temperature monitor |
Yes |
Voltage Monitor |
Yes |
Certification & Approvals
Details |
|---|
Certification |
CE, EAC, ROHS |
IP |
20 |
