Specifications
Details |
|---|
Product code |
CSS610-1Gi-7R-2S+OUT |
Dimensions |
304 x 212 x 71 mm |
Operating System |
SwitchOS Lite |
Storage size |
64 KB |
Storage type |
FLASH |
MTBF |
Approximately 200'000 hours at 25C |
Tested ambient temperature |
-40°C to 70°C |
Powering
Details |
|---|
Number of DC inputs |
3 (DC jack, 2-pin terminal, PoE-IN) |
DC jack input Voltage |
12-57 V |
2-pin terminal input Voltage |
12-57 V |
Max power consumption |
29 W |
Max power consumption without attachments |
7 W |
FAN count |
Passive |
PoE in |
Passive PoE |
PoE in input Voltage |
12-57 V |
PoE-out
Details |
|---|
PoE-out ports |
Ether8 |
PoE out |
Passive PoE |
Max out per port output (input 18-30 V) |
600 mA |
Max out per port output (input 30-57 V) |
450 mA |
Ethernet
Details |
|---|
10/100/1000 Ethernet ports |
8 |
Number of 1G Ethernet ports with Reverse PoE (PoE-in) |
7 |
Number of 1G Ethernet ports with PoE-out |
1 |
Fiber
Certification & Approvals
Details |
|---|
Certification |
CE, EAC, ROHS |
IP |
IP54 |
Dodatočné parametre
|
|
Routre a firewally |
|
|
24 mesiacov
|
|
|
2 kg
|
|
|
4752224000033
|
|
|
1 |
|
|
0 |
|
|
0 |
|
|
CSS |
|
|
0 |
|
|
Nie |
|
|
Nedefinované |
|
|
0 |
|
|
8 |
|
|
SwOS |
|
|
Áno |
|
|
Desktop |
|
|
Nie |
|
|
0 |
|
|
SFP+ |
|
|
Mikrotik - HW |
|
|
0 |
