Specifications
Details |
|---|
Product code |
H53UiG-5HaxQ2HaxQ |
Architecture |
ARM 64bit |
CPU |
IPQ-8072A |
CPU core count |
4 |
CPU nominal frequency |
2208 MHz |
Switch chip model |
IPQ-8072 |
RouterOS license |
6 |
Operating System |
RouterOS v7 |
Size of RAM |
1 GB |
Storage size |
128 MB |
Storage type |
NAND |
MTBF |
Approximately 200'000 hours at 25C |
Tested ambient temperature |
-40°C to 70°C |
Wireless capabilities
Details |
|---|
Wireless 2.4 GHz Max data rate |
1148 Mbit/s |
Wireless 2.4 GHz number of chains |
4 |
Wireless 2.4 GHz standards |
802.11b/g/n/ax |
Antenna gain dBi for 2.4 GHz |
5 |
Wireless 2.4 GHz chip model |
QCN-5024 |
Wireless 2.4 GHz generation |
Wi-Fi 6 |
Wireless 5 GHz Max data rate |
2400 Mbit/s |
Wireless 5 GHz number of chains |
4 |
Wireless 5 GHz standards |
802.11a/n/ac/ax |
Antenna gain dBi for 5 GHz |
6 |
Wireless 5 GHz chip model |
QCN-5054 |
Wireless 5 GHz generation |
Wi-Fi 6 |
WiFi speed |
AX3600 |
Ethernet
Details |
|---|
10/100/1000 Ethernet ports |
5 |
Number of 1G Ethernet ports with PoE-out |
1 |
Peripherals
Details |
|---|
Number of USB ports |
1 |
USB Power Reset |
Yes |
USB slot type |
USB 3.0 type A |
Max USB current (A) |
1.5 |
Powering
Details |
|---|
Number of DC inputs |
1 (DC jack) |
DC jack input Voltage |
18-57 V |
Max power consumption |
55 W |
Max power consumption without attachments |
18 W |
Cooling type |
Passive |
PoE-out
Details |
|---|
PoE-out ports |
Ether5 |
PoE out |
Passive PoE up to 57V |
Max out per port output (input 18-30 V) |
600 mA |
Max out per port output (input 30-57 V) |
500 mA |
Max total out (A) |
0.600 A |
Total output current |
0.600 |
Total output power |
22.8 |
Dodatočné parametre
|
|
Routre a firewally |
|
|
24 mesiacov
|
|
|
1.31 kg
|
|
|
4752224009135
|
|
|
Nie |
|
|
0 |
|
|
5 |
|
|
0 |
|
|
Nie |
|
|
1 |
|
|
2,0 GHz (4 jadrá) |
|
|
Nie |
|
|
1024 |
|
|
1 |
|
|
0 |
|
|
Desktop |
|
|
Nie |
|
|
0 |
|
|
L6 |
|
|
Áno |
|
|
Iné |
|
|
0 |
|
|
Mikrotik - HW |
|
Položka bola vypredaná…
|
