Specifications
Details |
|---|
Product code |
L11UG-5HaxD-NB |
Architecture |
ARM |
CPU |
IPQ-5010 |
CPU core count |
2 |
CPU nominal frequency |
800 MHz |
RouterOS license |
4 |
Operating System |
RouterOS v7 |
Size of RAM |
256 MB |
Storage size |
128 MB |
Storage type |
NAND |
MTBF |
Approximately 200'000 hours at 25C |
Tested ambient temperature |
-40°C to 70°C |
Powering
Details |
|---|
Number of DC inputs |
1 (PoE-IN) |
Max power consumption |
15 W |
Max power consumption without attachments |
6 W |
Cooling type |
Passive |
PoE in |
Passive PoE |
PoE in input Voltage |
18-28 V |
Wireless specifications
Details |
|---|
Wireless 5 GHz Max data rate |
2400 Mbit/s |
Wireless 5 GHz number of chains |
2 |
Wireless 5 GHz standards |
802.11a/n/ac/ax |
Wireless 5 GHz chip model |
QCN-6102 |
Wireless 5 GHz generation |
Wi-Fi 6 |
Ethernet
Details |
|---|
10/100/1000 Ethernet ports |
1 |
Peripherals
Details |
|---|
Number of USB ports |
1 |
USB Power Reset |
Yes |
USB slot type |
USB type A |
Max USB current (A) |
1.5 |
Other
Details |
|---|
PCB temperature monitor |
Yes |
Voltage Monitor |
Yes |
Beeper |
Yes |
Certification & Approvals
Details |
|---|
Certification |
CE, FCC, IC, EAC, ROHS |
IP |
54 |
