Specifications
Details |
|---|
Product code |
RBD52G-5HacD2HnD-TC |
Architecture |
ARM 32bit |
CPU |
IPQ-4018 |
CPU core count |
4 |
CPU nominal frequency |
716 MHz |
Dimensions |
34 x 119 x 98mm |
License level |
4 |
Operating System |
RouterOS |
Size of RAM |
128 MB |
Storage size |
16 MB |
Storage type |
FLASH |
Tested ambient temperature |
-40°C to 50°C |
Powering
Details |
|---|
PoE in |
Passive PoE |
PoE in input Voltage |
18-28 V |
Number of DC inputs |
2 (DC jack, PoE-IN) |
DC jack input Voltage |
12-30 V |
Max power consumption |
21 W |
Max power consumption without attachments |
16 W |
Wireless
Details |
|---|
Wireless 2.4 GHz number of chains |
2 |
Wireless 2.4 GHz Max data rate |
300 Mbit/s |
Wireless 2.4 GHz standards |
802.11b/g/n |
AC speed |
AC1200 |
Antenna gain dBi for 2.4 GHz |
2.5 |
Wireless 2.4 GHz chip model |
IPQ-4018 |
Wireless 5 GHz number of chains |
2 |
Wireless 5 GHz Max data rate |
867 Mbit/s |
Wireless 5 GHz standards |
802.11a/n/ac |
Antenna gain dBi for 5 GHz |
2.5 |
Wireless 5 GHz chip model |
IPQ-4018 |
Ethernet
Details |
|---|
10/100/1000 Ethernet ports |
5 |
Peripherals
Details |
|---|
Number of USB ports |
1 |
USB Power Reset |
Yes |
USB slot type |
USB type A |
Max USB current (A) |
1 |
Other
Wireless specifications
2.4 GHz |
Transmit (dBm) |
Receive Sensitivity |
|---|
1MBit/s |
27 |
-100 |
11MBit/s |
27 |
-94 |
6MBit/s |
27 |
-96 |
54MBit/s |
24 |
-78 |
MCS0 |
27 |
-96 |
MCS7 |
23 |
-73 |
