Specifications
Details |
|---|
Product code |
CRS318-16P-2S+OUT |
Architecture |
ARM 32bit |
CPU |
98DX226S |
CPU core count |
1 |
CPU nominal frequency |
800 MHz |
Dimensions |
303 x 212 x 78 mm |
License level |
5 |
Operating System |
RouterOS/SwitchOS |
Size of RAM |
256 MB |
Storage size |
16 MB |
Storage type |
FLASH |
Tested ambient temperature |
-40°C to 70°C |
Powering
Details |
|---|
Number of DC inputs |
2 (DC jack) |
DC jack input Voltage |
18-30 V / 48-57 V |
Max power consumption |
316 W |
Max power consumption without attachments |
16 W |
FAN count |
Passive |
PoE-out
Details |
|---|
PoE-out ports |
Ether1-Ether16 |
PoE out |
802.3af/at |
Max out per port output (input < 30 V) |
1.1 A |
Max out per port output (input > 30 V) |
0.6 A |
Max total out (A) |
2.8A (18V-30V) & 1.4A (48V-57V) x2 A |
Ethernet
Details |
|---|
10/100/1000 Ethernet ports |
16 |
Number of 1G Ethernet ports with PoE-out |
16 |
Fiber
Other
Details |
|---|
CPU temperature monitor |
Yes |
Voltage Monitor |
Yes |
Certification & Approvals
Details |
|---|
Certification |
CE/RED, EAC, ROHS |
