Specifications
Details |
|---|
Product code |
L009UiGS-RM |
Architecture |
ARM |
CPU |
IPQ-5018 |
CPU core count |
2 |
CPU nominal frequency |
800 MHz |
Switch chip model |
88E6190 |
RouterOS license |
5 |
Operating System |
RouterOS v7 |
Size of RAM |
512 MB |
Storage size |
128 MB |
Storage type |
NAND |
MTBF |
Approximately 200'000 hours at 25C |
Tested ambient temperature |
-40°C to 70°C |
Powering
Details |
|---|
Number of DC inputs |
2 (DC jack, PoE-IN) |
DC jack input Voltage |
24-56 V |
Max power consumption |
40 W |
Max power consumption without attachments |
8 W |
Cooling type |
Passive |
PoE in |
802.3af/at |
PoE in input Voltage |
24-56 V |
PoE-out
Details |
|---|
PoE-out ports |
Ether8 |
PoE out |
Passive PoE |
Max out per port output (input 18-30 V) |
1 A |
Max out per port output (input 30-57 V) |
450 mA |
Max total out (A) |
1 A |
Ethernet
Details |
|---|
10/100/1000 Ethernet ports |
8 |
Number of 1G Ethernet ports with PoE-out |
1 |
Fiber
Details |
|---|
SFP ports |
1 (2.5G supported) |
Peripherals
Details |
|---|
Serial console port |
RJ45 |
Number of USB ports |
1 |
USB Power Reset |
Yes |
USB slot type |
USB 3.0 type A |
Max USB current (A) |
1.5 |
Other
Certification & Approvals
Details |
|---|
Certification |
CE, EAC, ROHS |
IP |
20 |
Dodatočné parametre
|
|
Routre a firewally |
|
|
24 mesiacov
|
|
|
0.9 kg
|
|
|
8 |
|
|
Lxxx |
|
|
1 |
|
|
L5 |
|
|
SFP |
|
|
Nie |
|
|
512 |
|
|
0 |
|
|
0 |
|
|
1 |
|
|
0 |
|
|
0 |
|
|
Mikrotik - HW |
|
|
Nie |
|
|
Nie |
|
|
800 MHz |
|
|
Rackmount |
|
|
Áno |
|
|
0 |
