Specifications
Details |
|---|
Product code |
RB912R-2nD-LTm |
Architecture |
MIPSBE |
CPU |
QCA9531 |
CPU core count |
1 |
CPU nominal frequency |
650 MHz |
Dimensions |
139 x 77 x 28,5 mm |
License level |
4 |
Operating System |
RouterOS |
Size of RAM |
64 MB |
Storage size |
16 MB |
Storage type |
FLASH |
Tested ambient temperature |
-40°C to 70°C |
Powering
Details |
|---|
MicroUSB input Voltage |
5-5 V |
PoE in |
802.3af/at |
PoE in input Voltage |
12-57 V |
Number of DC inputs |
3 (PoE-IN, DC jack, MicroUSB) |
DC jack input Voltage |
8-30 V |
Max power consumption |
9 W |
Max power consumption without attachments |
4 W |
Wireless
Details |
|---|
Wireless 2.4 GHz number of chains |
2 |
Wireless 2.4 GHz Max data rate |
300 Mbit/s |
Wireless 2.4 GHz standards |
802.11b/g/n |
Antenna gain dBi for 2.4 GHz |
1.5 |
Wireless 2.4 GHz chip model |
QCA9531 |
Ethernet
Details |
|---|
10/100 Ethernet ports |
1 |
Peripherals
Details |
|---|
Number of SIM slots |
2 Modem (Mini SIM) |
MiniPCI-e slots |
1 |
Serial port |
RS232 |
Number of USB ports |
1 |
USB Power Reset |
Yes |
USB slot type |
microUSB type AB |
Max USB current (A) |
1 |
Other
Wireless specifications
2.4 GHz |
Transmit (dBm) |
Receive Sensitivity |
|---|
1MBit/s |
22 |
-96 |
11MBit/s |
22 |
-89 |
6MBit/s |
20 |
-93 |
54MBit/s |
18 |
-74 |
MCS0 |
20 |
-93 |
MCS7 |
16 |
-71 |
Dodatočné parametre
|
|
Routre a firewally |
|
|
24 mesiacov
|
|
|
0.48 kg
|
|
|
4752224000637
|
|
|
0 |
|
|
Mikrotik - HW |
|
|
1 |
|
|
650 MHz |
|
|
1 |
|
|
1 |
|
|
Nie |
|
|
0 |
|
|
Áno |
|
|
Áno |
|
|
Nie |
|
|
0 |
|
|
RB/9xxx |
|
|
0 |
|
|
64 |
|
|
0 |
|
|
L4 |
|
|
Desktop |
