Specifications
Details |
|---|
Product code |
RBSXTG-5HPacD-SA |
Architecture |
MIPSBE |
CPU |
QCA9557 |
CPU core count |
1 |
CPU nominal frequency |
720 MHz |
License level |
4 |
Operating System |
RouterOS |
Size of RAM |
128 MB |
Storage size |
128 MB |
Storage type |
NAND |
Tested ambient temperature |
-40°C to 70°C |
Powering
Details |
|---|
PoE in |
802.3af/at |
PoE in input Voltage |
12-57 V |
Number of DC inputs |
1 (PoE-IN) |
Max power consumption |
12 W |
Wireless
Details |
|---|
Antenna gain dBi for 5 GHz |
14 |
Wireless 5 GHz standards |
802.11a/n/ac |
Wi-Fi generation |
5 |
Wireless 5 GHz Max data rate |
867 Mbit/s |
Wireless 5 GHz number of chains |
2 |
Wireless 5 GHz chip model |
QCA9892 |
Ethernet
Details |
|---|
10/100/1000 Ethernet ports |
1 |
Peripherals
Details |
|---|
Number of USB ports |
1 |
USB Power Reset |
Yes |
USB slot type |
USB type A |
Max USB current (A) |
1 |
Other
Details |
|---|
PCB temperature monitor |
Yes |
Voltage Monitor |
Yes |
Wireless specifications
5 GHz |
Transmit (dBm) |
Receive Sensitivity |
|---|
6MBit/s |
31 |
-96 |
54MBit/s |
28 |
-81 |
MCS0 |
30 |
-96 |
MCS7 |
27 |
-77 |
MCS9 |
22 |
-72 |
