Specifications
Details |
|---|
Product code |
RBcAPL-2nD |
Architecture |
MIPSBE |
CPU |
QCA9533 |
CPU core count |
1 |
CPU nominal frequency |
650 MHz |
Dimensions |
Wall case: 88 x 52 x 20 mm Ceiling case: ?88 mm x 20 mm |
License level |
4 |
Operating System |
RouterOS |
Size of RAM |
64 MB |
Storage size |
16 MB |
Storage type |
FLASH |
Tested ambient temperature |
-40°C to 70°C |
Powering
Details |
|---|
MicroUSB input Voltage |
5-5 V |
PoE in |
802.3af/at |
PoE in input Voltage |
10-60 V |
Number of DC inputs |
2 (PoE-IN, MicroUSB) |
Max power consumption |
4 W |
Wireless
Details |
|---|
Wireless 2.4 GHz number of chains |
2 |
Wireless 2.4 GHz Max data rate |
300 Mbit/s |
Wireless 2.4 GHz standards |
802.11b/g/n |
Antenna gain dBi for 2.4 GHz |
1.5 |
Wireless 2.4 GHz chip model |
QCA9533 |
Ethernet
Details |
|---|
10/100 Ethernet ports |
1 |
Peripherals
Details |
|---|
Number of USB ports |
1 |
USB slot type |
microUSB type AB |
Max USB current (A) |
1 |
Wireless specifications
2.4 GHz |
Transmit (dBm) |
Receive Sensitivity |
|---|
1MBit/s |
22 |
-96 |
11MBit/s |
22 |
-89 |
6MBit/s |
20 |
-93 |
54MBit/s |
18 |
-74 |
MCS0 |
20 |
-93 |
MCS7 |
16 |
-71 |
