Specifications
Details |
|---|
Product code |
CRS354-48P-4S+2Q+RM |
Architecture |
MIPSBE |
CPU |
QCA9531 |
CPU core count |
1 |
CPU nominal frequency |
650 MHz |
Dimensions |
297 x 443 x 44 mm |
License level |
5 |
Operating System |
RouterOS |
Size of RAM |
64 MB |
Storage size |
16 MB |
Storage type |
FLASH |
Tested ambient temperature |
-20°C to 60°C |
|
Powering
Details |
|---|
Number of AC inputs |
1 |
PoE out |
IEEE 802.3at/af and 26 or 53 V Passive PoE |
PoE out ports |
Ether1 - Ether48 |
PoE out max per port (low voltage 26V) |
26 W |
PoE out max per port (high voltage 53V) |
30 W |
Max. total out (low power 26V) |
27A |
Max. total out (high power 53V) |
13,2A |
AC input range |
100-240 |
Max power consumption |
800 W |
Max power consumption without attachments |
85 W |
Ethernet
Details |
|---|
10/100 Ethernet ports |
1 |
10/100/1000 Ethernet ports |
48 |
Fiber
Details |
|---|
SFP+ ports |
4 |
Number of 40G QSFP+ ports |
2 |
Peripherals
Other
Details |
|---|
PCB temperature monitor |
Yes |
Voltage Monitor |
Yes |
Dodatočné parametre
|
|
Routre a firewally |
|
|
24 mesiacov
|
|
|
8.05 kg
|
|
|
QSFP+/SFP+ |
|
|
1 |
|
|
48 |
|
|
64 |
|
|
1 |
|
|
Mikrotik - HW |
|
|
650 MHz |
|
|
L5 |
|
|
Rackmount |
|
|
CRS |
|
|
Áno |
|
|
Nie |
|
|
Nie |
