Ubiquiti EdgeSwitch 48xGb 2xSFP 2xSFP+ PoE+ ES-48-500W

Layer 2/3, PoE+ switch with (48) Gigabit RJ45 ports, (2) SFP+ ports, (2) SFP ports, and a 500W power supply.

(48) GbE RJ45 ports

(2) SFP and (2) SFP+ ports

500W total PoE availability

Rack-mountable, 1U

Technical Specifications

Mechanical

Dimensions 485 x 43.7 x 374.6 mm (19.1 x 1.7 x 14.8")

Weight 6.1 kg (13.5 lb)

Hardware

Networking interface (48) 10/100/1000 Mbps RJ45 Ethernet ports

(2) 1/10 Gbps SFP+ Ethernet ports

(2) 1 Gbps SFP Ethernet ports

Management interface (1) RJ45 serial port, Ethernet In/Out-Band

Total non-blocking throughput 70 Gbps

Switching capacity 140 Gbps

Forwarding rate 104.16 Mpps

Power method 100-240V AC, 50-60 Hz, universal input

Power supply AC/DC, internal, 500W

Max. power consumption Includes PoE output: 500W

Excludes PoE output: 64W

ESD/EMP protection Air/contact: ±24 kV

LEDs RJ45 pports: PoE, speed/link/activity

SFP ports: speed/link/activity

Rackmount Yes, 1U high

Shock and vibration ETSI300-019-1.4 Standard

Ambient operating temperature -5 to 40° C (23 to 104° F)

Ambient operating humidity 5 to 95% noncondensing

Certifications CE, FCC, IC

PoE Per Port

PoE interfaces PoE/PoE+ (Pins 1, 2+; 3, 6-)

24V DC passive PoE (Pins 4, 5+; 7, 8-)

Max. PoE+ wattage per port by PSE 34.2W

Voltage range PoE+ mode 50–57V

Max. passive PoE wattage per port 17W

24V passive PoE voltage range 20-27V
