Ubiquiti UniFi Switch USW-Pro-24

Technical Specifications



Mechanical

Dimensions 442 x 285 x 44 mm (17.4 x 11.2 x 1.7")

Weight  Without mounting brackets: 3.5 kg (7.7 lb)

With mounting brackets: 3.6 kg (7.9 lb)

Enclosure material SGCC steel



Hardware

Management interface Ethernet In-Band

Networking interface (24) GbE RJ45 ports

(2) 1/10G SFP+ ports

Total non-blocking throughput 44 Gbps

Switching capacity 88 Gbps

Forwarding rate 65.472 Mpps

Power method  (1) Universal input, 100—240V AC, 50/60 Hz

(1) USP-RPS DC input 11.5V DC, 2.61A

Power supply AC/DC, internal, 36W

Supported voltage range 100—240V AC

Max. power consumption 30W

ESD/EMP protection Air: ± 16kV, contact: ± 12kV

LCM display (1) 1.3" touchscreen

Button Factory reset

Shock and vibration ETSI300-019-1.4 Standard

Ambient operating temperature -5 to 45° C (23 to 113° F)

Ambient operating humidity 10 to 90% noncondensing

Certifications CE, FCC, IC



Switching Features

Layer 2 features

IGMP snooping

STP / RSTP with priorities and port-level disable

Port isolation

Storm control

Voice VLAN

Port mirroring

LACP port aggregation

Multicast / broadcast rate limiting

MAC address blocking

Flow control

802.1X control

Jumbo frames

Proprietary loop protection

DHCP snooping / guarding

Egress rate limit

LLDP-MED

Port restricted by MAC

Device isolation with ACLs

Layer 3 features

DHCP for locally-managed networks

DHCP relay

Inter-VLAN routing between networks on same switch

Static routing between local networks

Network isolation with ACLs



LEDs

System Status

Ethernet Speed/link/activity

SFP+ Speed/link/activity

RPS Status



Application Requirements

UniFi Network  Version 5.12.11 and later
