Ubiquiti USW-Pro-Max-48, UniFi Switch Pro Max 48

Technical Specifications



Mechanical

Dimensions 442 x 325 x 44 mm (17.4 x 12.8 x 1.7")

Weight Without mounting brackets: 4.8 kg (10.6 lb)

With mounting brackets: 4.9 kg (10.8 lb)

Enclosure material SGCC steel



Hardware

Management interface Ethernet In-Band

Networking interface (32) GbE RJ45 ports

(16) 1/2.5 GbE RJ45 ports

(4) 10G SFP+ ports

Total non-blocking throughput 112 Gbps

Switching capacity 224 Gbps

Power method (1) Universal input, 100—240V AC, 50/60 Hz

(1) USP-RPS DC input

Power supply AC/DC, internal, 100W

Supported voltage range 100—240V AC

Max. power consumption 100W

LCM display  (1) 1.3" touchscreen

Button Factory reset

Ambient operating temperature -5 to 40° C (23 to 104° F)

Ambient operating humidity 10 to 90% noncondensing

Certifications CE, FCC, IC



Switching Features

Layer 2 features

IGMP snooping

STP / RSTP with priorities and port-level disable

Port isolation

Storm control

Voice VLAN

Port mirroring

LACP port aggregation

Multicast / broadcast rate limiting

MAC address blocking

Flow control

802.1X control

Jumbo frames

Proprietary loop protection

DHCP snooping / guarding

Egress rate limit

LLDP-MED

Port restricted by MAC

Device isolation with ACLs

Layer 3 features

DHCP for locally-managed networks

DHCP relay

Inter-VLAN routing between networks on same switch

Static routing between local networks

Network isolation with ACLs

Etherlighting™

Ethernet  Locating

Speed/link

Native VLAN/network

SFP+ Locating

Speed/link

Native VLAN/network



LEDs

System Status

RPS Status



Application Requirements

UniFi Network  Version 8.0.24 and later
