Ubiquiti Wave-Pro - UISP Wave Pro

Popis produktu

High-capacity 60 GHz radio that supports long-distance PtP (bridge) and PtMP links.

• Max. link range:



  • — PtP: Up to 15 km


  • — PtMP: Up to 8 km (Wave AP), up to 6 km (Wave AP Micro)






• Max. total throughput: 5.4 Gbps (2.7 Gbps duplex)


• 5 GHz weatherproof backup radio (Max. throughput: 800 Mbps)


• (2) 2.5 GbE and (1) 10G SFP+ ports


• Ergonomic transportation handle


• Precision alignment mount


• Integrated GPS & Bluetooth

Mechanical

Dimensions O424.4 x 166.2 mm (O16.7 x 6.5")

Weight Without mount: 2.8 kg (6.2 lb)

With mount: 4 kg (8.8 lb)

Enclosure material Aluminum alloy, UV stabilized plastic

Mount material Stainless steel

Pole mount diameter 25 to 76.2 mm (1 to 3") on pipe outer diameter

Wind loading 369 N at 200 km/h (83 lbf at 125 mph)

Weatherproofing IPX6



Hardware

Processor Quad-core ARM® Cortex®-A53 at 1.4 GHz

Memory DDR3L 512 MB

Networking interface (2) 2.5 GbE RJ45 ports

(1) 10G SFP+ port

Max. power consumption 26W

Power method Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-)

Passive PoE 2-pairs (4, 5+; 7, 8-), for 44–54V DC only

Power supply 48V DC, 0.65A, 2.5 GbE PoE adapter (Included)

Supported voltage range 44–54V DC

22–27V DC

GPS Yes

Button Factory reset

LEDs Power, (2) Ethernet, SFP+ , GPS, link

Ambient operating temperature -40 to 60° C (-40 to 140° F)

Ambient operating humidity 5 to 95% noncondensing

Certifications FCC, IC, CE



Software

Operating mode PtP, PtMP station

Ubiquiti specific features Integrated 60 GHz radio, discovery protocol, Wave technology

Services UISP, ping watchdog, NTP client, SNMP

Tools Antenna alignment, discovery utility, ping, trace route, speed test, cable test*, site survey*, traffic shaping**

*FW version 3.3.0 and later.

**FW version 3.4.0 and later.

Network Bridge/Router* mode

*Router is available in PtMP station mode only.

Application requirements UISP: Version 2.3.0 and later



System

Total throughput 5.4 Gbps (2.7 Gbps duplex)

Max. range PtP: Up to 15 km

PtMP: Up to 8 km (Wave AP), up to 6 km (Wave AP Micro)

Encryption WPA2-PSK (AES)



RF

Operating frequency* 57 to 71 GHz

*Depends on regulatory region.

Channel bandwidth 2160, 1080, 540* MHz

*FW version 3.3.0 and later.

Operating channels* 58320, 59400, 60480, 61560, 62640, 63720, 64800, 65880, 66960, 68040, 69120, 70200 MHz

*Depends on regulatory region.

Modulation 16QAM, QPSK

Antenna gain 46 dBi

Polarization Vertically linear

Beamwidth Azimuth: 3 dB 1.3°

Elevation: 3 dB 1.3°



Back-Up RF

WiFi Standard 802.11ax (WiFi 6)

Operating frequency*

US/CA

Worldwide

U-NII-1 5150 - 5250 MHz

U-NII-2A 5250 - 5350 MHz

U-NII-2C 5470 - 5725 MHz

U-NII-3 5725 - 5850 MHz

5150 - 5875 MHz

*Depends on regulatory region.

Channel bandwidth 20, 40, 80 MHz

Max. conducted TX power 27 dBm

Modulation BPSK (1⁄2), QPSK (1⁄2), QPSK (3⁄4), 16QAM (1⁄2), 16QAM (3⁄4), 64QAM (2⁄3), 64QAM (3⁄4), 64QAM (5⁄6), 256QAM (3⁄4), 256QAM (5⁄6), 1024QAM (3⁄4), 1024QAM (5⁄6)

Antenna gain 22 dBi

Polarization Dual-linear

Beamwidth Azimuth: 3 dB 8°

Elevation: 3 dB 8°

Cross-pol isolation 20 dB



LEDs

Power Flashing white: bootup in progress

White: not connected to UISP application

Blue: connected to UISP application

Flashing blue: locate in progress

Blue/white: firmware upgrade in progress

Ethernet (2) Flashing blue: Ethernet traffic detected

SFP+ (1) Flashing blue: SFP+ traffic detected

Links White: 5 GHz link

Blue: 60 GHz link

GPS Blue: receiving at least (4) GPS satellite signal
